With the SX12:
Collect millions of points for a 360 degree point cloud
Control land topographic collection/measurements during site surveying
Document every visible feature on a project, reducing costly site visits
Check grade for inspection and monitoring
Safely and efficiently scan road corridors and intersection details such as roadway surfaces, overhead power lines and lane markings
Safely gather accurate survey data in trenches, on cliffs, near moving equipment, and in other hazardous areas without putting a surveyor in danger
Capture rich, accurate and complete geometrical and visual documentation of as-builts
Trimble SX12 Key Features
The SX12 is the one instrument you need to handle any survey project by integrating surveying, imaging, and 3D scanning capabilities into your everyday workflow.
Collect survey data, VISION imagery, and high-speed scans easily with Trimble Access field software and the SX12’s Lightning 3DM.
Process seamless with Trimble Business Center office software or with Trimble RealWorks Office Software for more advanced scan processing
Share with anyone using web-based Trimble Clarity
Relay on your equipment for years to come with the Trimble Service and Warranty Guarantee
Aim, measure, and mark effortlessly. A green focusable laster pointer yields the smallest spot size in the industry, just 6mm at 100m
Stay eye-safe without compromising laser visibility
The SX12 is a high-accuracy total station and captures high-quality scan data: it has a 1″ angular accuracy, 1.5 mm scan range noise at 200 m, and a 14 mm diameter EDM laser spot at 100 m. Even at long range, the data capture is quick, with a 26.6 kHz scan measurement rate up to 600 m. The total station measuring time in prism mode is 1.6 s, while in DR mode this is 1.2 s.
A new green, focusable Class 1M laser pointer is safe for viewing with the naked eye, offers high-power visibility, and easy to see even at a distance. The laser pointer is very small, bright, and still eye-safe and has a 3 mm diameter laser pointer spot at 50 meters. The SX 12 offers simple navigation and documentation with a Trimble VISION camera system, which consists of three integrated and calibrated cameras in the telescope.
Trimble Geospatial announced the release of a new model of the SX12 Scanning Total Station. Compared to its predecessor, the SX10, the new total station has an updated built-in camera system and a laser pointer. Increasing the resolution of the built-in cameras allowed for a smaller pixel size, which, together with improved processing, resulted in sharper images with richer colors and less noise (especially in low light).
Trimble SX12 Key Features
The SX12 is the one instrument you need to handle any survey project by integrating surveying, imaging, and 3D scanning capabilities into your everyday workflow.
Collect survey data, VISION imagery, and high-speed scans easily with Trimble Access field software and the SX12’s Lightning 3DM.
Process seamless with Trimble Business Center office software or with Trimble RealWorks Office Software for more advanced scan processing
Share with anyone using web-based Trimble Clarity
Relay on your equipment for years to come with the Trimble Service and Warranty Guarantee
Aim, measure, and mark effortlessly. A green focusable laster pointer yields the smallest spot size in the industry, just 6mm at 100m
Stay eye-safe without compromising laser visibility
The SX12 is a high-accuracy total station and captures high-quality scan data: it has a 1″ angular accuracy, 1.5 mm scan range noise at 200 m, and a 14 mm diameter EDM laser spot at 100 m. Even at long range, the data capture is quick, with a 26.6 kHz scan measurement rate up to 600 m. The total station measuring time in prism mode is 1.6 s, while in DR mode this is 1.2 s.
A new green, focusable Class 1M laser pointer is safe for viewing with the naked eye, offers high-power visibility, and easy to see even at a distance. The laser pointer is very small, bright, and still eye-safe and has a 3 mm diameter laser pointer spot at 50 meters. The SX 12 offers simple navigation and documentation with a Trimble VISION camera system, which consists of three integrated and calibrated cameras in the telescope.
Trimble Geospatial announced the release of a new model of the SX12 Scanning Total Station. Compared to its predecessor, the SX10, the new total station has an updated built-in camera system and a laser pointer. Increasing the resolution of the built-in cameras allowed for a smaller pixel s
ize, which, together with improved processing, resulted in sharper images with richer colors and less noise (especially in low light).
