Description
Model Number: 9684554
Features:
The Palmgren Engine Lathe is designed to handle heavy metal removal and
precision fine tolerance turning with ease. Equipped with a convenient DRO and glass scales,
this machine offers accurate and reliable performance.
The headstock is engineered for maximum power and smooth finishing,
while the helical precision cut gears run in a constant oil bath for durability.
The main spindle, made of high alloy steel, is mounted in precision taper roller bearings for added control.
The user-friendly control panel is designed for operator convenience,
and the wide bed ways are made of stabilized cast iron for a lifetime of use.
The universal gear box offers a broad range of feed and thread selections,
making it ideal for both inch and metric threads. All gears are hardened and
turn on anti-friction bearings, ensuring consistent and reliable performance.
Built and inspected to the DIN 8606 toolmakers precision lathe standard,
this all-purpose lathe is perfect for tool rooms, die and mold shops,
fabrication shops, and maintenance departments.
Specifications:
Motor: 7.5HP – 230/460V – 3PH
Swing Over Bed: 18″
Distance Between Centers: 80″
Spindle Taper: MT6
Spindle Bore: 3-1/8″
Number of Spindle Speeds: 12
Spindle Speed: 30-2400 RPM
Bed Width: 11-3/4″
Cross Travel: 11.2″
Compound Travel: 5″
Tailstock Taper: MT4
Tailstock Travel: 4-3/4″
Thread Range (In.): 2/1/1940
Thread Range (mm): 0.1-14
Longitudinal Feed Rates: 0.001 – 0.033″
Overall Length: 128″
Overall Width: 49″
Overall Height: 63″
