Description
The geo-FENNEL total station FTS 310 is an innovative solution with reflectorless
distance measuring module with a range of over 300 m (with reflector up to over 5,000 m).
Equipped with an electronic bubble level, the FTS 310 offers an exceptionally powerful,
cost-effective solution for a wide range of general and
specialised applications in construction and engineering.
Integrated and comprehensive software package
Choice of applications
Construction & engineering surveying
Stake-out
Point-to-line, bends
Point-to-point
Free stationing
Height determination
2D/3D interface
Right-angle coordinates, polar coordinates
Roads
Features
Easy-to-use on-board software
Easy to read display also by direct sunlight
Fast import and export of different
data formats without an additional software
Fast and accurate measurements
Bluetooth connection to other software solutions possible
Compact and smart design
Included
Charger
NimH Akku
Data Cable
Container
Stake Out Aid RS 96
Specifications
Properties Details
Laser Class 2
Resolving Power 3″
Working Range 1.5 – 300 m (Reflectorless), 1.5 – 500 m
(Reflective tape target), 1.5 – 5000 m (Single standard prism)
Weight 6.5 kg
Extended Size 190 x 210 x 350 mm
Temperature Range -20°C to 55°C
Operating Time 2 x 6 h
Visible Laser Beam ± 1.5 mm / 1.5 m
Accuracy ± 2 mm + 2 ppm
(working range), 2″ (angle measurement)
Field of View 1°30′
Circular Bubble 8′ / 2 mm
