Description
The geo-FENNEL Total station FTS 300 is an innovative solution
with reflectorless distance measuring module with a range of over 600 m
(with reflector up to over 5,000 m). Equipped with an electronic bubble level,
FTS 300 offers an exceptionally powerful, cost-effective solution for a wide range of
general and specialised applications in construction and engineering.
Integrated and comprehensive software package
Stake-out
Point-to-line
Height determination
Free stationing
Indirect height measurement
Roads
Area determination
Right-angle coordinates, polar coordinatesPoint-to-point
Features
Easy-to-use on-board software
Easy to read display also by direct sunlight
Fast import and export of different data formats without an additional software
Fast and accurate measurements
Intensity of the laser plummet can be changed gradually
Compact and smart design
Included
Charger
NimH Akku
Data Cable
Container
Stake Out Aid RS 96
Specifications
Specification Details
Laser Class 2
Dust / Water Protection IP 56
Extended Size 190 x 210 x 350 mm
Temperature Range -20°C to 55°C
Operating Time 2 x 6 h
Visible Laser Beam ± 1.5 mm / 1.5 m
Accuracy ± 2 mm + 2 ppm (working range), 2″ (angle measurement)
Working Range 1.5 – 600 m (Reflective tape target),
1.5 – 600 m (Reflectorless), 1.5 – 5000 m (Single standard prism)
Resolving Power 3″
Field of View 1°30′
Power Supply NiMH
Plate Level
