Fluke 1586-2586 Module, Hi-Capacity Module with Relay Card (item no. 4409835)

Description

If you want to configure the 1586A yourself to work with the 1586-2586 High-Capacity Module,
you will need a relay card. However, if you already have a slot in the back panel of
the 1586A configured for use with the 1586-2586, then you don’t need another relay card.
You can simply slide the 1586-2586 High-Capacity Module into the preconfigured slot
and begin taking measurements. The 1586-2586 High-Capacity Module is designed
with universal input channels to measure temperature, resistance, dc voltage,
and dc current for data acquisition applications
where channel count and scan speed are important.

SPECIFICATIONS
Maximum Input
50 V
Offset Voltage
<2 μV
3-Wire Internal Resistance Mismatch
<50 mΩ
Basic CJC Accuracy
0.6 °C
1586A
Super-DAQ Precision Temperature Scanner
