Description
The Radiodetection RD312 Metal Cover Locator features a high standard of simplicity and reliability,
ideal for enhancing the efficiency of on-site work and achieving fast results.
This metal cover locator is capable of detecting items buried beneath a variety of substances
including road surfaces, gravel, grass or snow. By ignoring small items such as coins and cans,
the RD312 is suitable for locating a wide array of hidden covers and more:
Valve box covers
Vault covers
Fuel tanks
Reinforced rods in concrete (rebar)
Manhole covers
Automatically adjusting sensitivity to suit the local operating environment,
the Radiodetection RD312 Locator remains at peak performance even when near
metal fences or under parked cars. With no interference from passing vehicles
and a tactile colour-coded button interface, this portable unit is easy-to-use
and incredibly versatile. A varying pitch tone is produced by the loudspeaker
to indicate the presence of a buried object, with the highest pitch indicating
maximum response over target. However, should the user employ the optional
headphones this will disable the speaker from producing any audio tones.
Other features built-into the RD312 include an
audio battery “OK” indication and Auto Gain Reset function.
SPECIFICATIONS
Weight: 1kg (2.2lbs)
Weight Shipping: 2kg (4.4lbs)
Dimensions: 78 cm x 25 cm x 10 cm (28″ x 10″ x 4″)
Dimensions Ship: 79 cm x 26 cm x 14 cm (31″ x 10.2″ x 5.5″)
Head/Housing: High impact ABS mid-black plastic
Stem: 22mm aluminium tube
Weatherproof: NEMA 3R and IP54
Drop Test: 1m (3ft) onto concrete
Operating Modes: ON / sensitivity /reset and OFF
Detection Range: Absolute limits of location range cannot be accurately specified
Operating Temp Range: -15ºC to +50ºC (5ºF to + 122ºF)
Auto Gain Reset Feature: Yes
Batteries: 1 x 6LR61 9V Alkaline
Safety:
Quality Control – BS EN ISO 9001 2008
EMC – CE complies with European EMC Directive 2004/108/EC
